The following needs can be met by linking eBinder with a JTAG probe with the target hardware:

• Use of the eBinder functions to support multiprogramming if the debugging ports (serial, Ethernet, etc.) required for eBinder debugging communication are not available due to hardware limitations
• Debugging a program in flash memory
• Breaking the entire system and using functions specific to JTAG

Communication/execution features

eBinder provides the following two functions by linking via the JTAG standard.

Communication function

Using the JTAG port as a debugging port with the JTAG probe as a communication pathway makes it possible to use all eBinder functions, including eBinder's multi-programming tool, system analysis tool, software component packaging tool, and others.

Execution control function

Here is an overview of eBinder-supported JTAG functions.

Main JTAG debugging specific functions

Hardware reset Forced break Step execution Hardware break (command execution break/memory access break) Software break (breaks program code on RAM/flash memory) Download to / editing of RAM / flash memory Depending on the hardware and JTAG probe linked with eBinder, some functions may not be available.

Compatible JTAG units

eBinder supports the following JTAG probes of our global partners

JTAG unit name	Manufacturer	Functions
DSTREAM		Communication/execution control linkage
PARTNER-Jet2		Communication/execution control linkage
adviceXross adviceLUNA II		Communication/execution control linkage
J-Link		Communication/execution control linkage
